XF + GM
XF + Growth Media
The lightweight built-up green roof system
24 lbs. per square foot with 2” of growth media
The XF + GM built-up system is a suitable assembly for retrofitting projects - especially in southern climates which required more moisture during dry seasons. An extra two inches of growing media not only increases the water retention capacity, but also provides the nutrients and moisture necessary for a more varied selection of vegetation.
Add 6.6 lbs per additional inch of growth media
Downloads
Durable LDPE plastic layer placed over the waterproofing membrane to prevent root encroachment into the building components.
PROTECT: Root Barrier
Polymeric entanglements fused to a geotextile fabric allowing excess water drainage below vegetated layers.
DRAIN: Drainage Mat
Non-woven fabric used to facilitate distribution and storage of water within the root zone.
RETAIN: Fabric Border
Lightweight, extensive, pre-vegetated green roof blanket, modular system, cuttings and plugs. Regionally grown and bio-diverse.
GROW: Plantings
GROW: Growth Media
Elements to contain, and serve as an additional barrier between the vegetated system and the roof structures.
ACCESSORIES
